Fire Alarm Controller
CV9101

Allows Cavius family of RF alarms to be remotely tested and hushed from a central location.
Up to 32 devices can be interlinked within a house group.
Single button for alarm test/hush.
10-years battery life.

Enables manual execution of the following functions without requiring direct, physical access to the installed alarms:

Testing of RF connection
Silencing of alarms (hush feature)
Increases accessibility for the elderly or disabled who would otherwise be unable to easily test or hush the alarms.
Enables residents of properties with high ceilings to remotely test or hush their alarms.

Order Code	CV9101
Compatibility	Cavius family of wireless alarms
Primary Power Source	3V Lithium Battery
Product and Battery Life	10-years operation
Low Battery Warning	Short beep and amber LED flashes every 48 seconds for 30 days
Visual Indicators	Red, amber and green status LED
Front Button Function	Test or silence interconnected device
Rear Switch Function	RF LEARN mode
Wireless Range	> 100m in free space
Operating Temperature Range	0°C to 40°C
Storage Temperature Range	20°C to +60°C
Humidity Range	0% to 90% RH, non-condensing
Alarm Dimensions	79 x 79 x 23mm
Alarm Weight (including batteries)	62g
Mounting Options	Wall-mounted (with tamperproof latch) and freestanding
Number of Interconnected Units	32
Case Quantity	1 unit
Compliance	CE, UKCA
Warranty	10-year manufacturer’s warranty

Key Features

Enables manual execution of the following functions without requiring direct, physical access to the installed alarms:

Testing of RF connection
Silencing of alarms (hush feature)
Increases accessibility for the elderly or disabled who would otherwise be unable to easily test or hush the alarms.
Enables residents of properties with high ceilings to remotely test or hush their alarms.

Specifications

Order Code	CV9101
Compatibility	Cavius family of wireless alarms
Primary Power Source	3V Lithium Battery
Product and Battery Life	10-years operation
Low Battery Warning	Short beep and amber LED flashes every 48 seconds for 30 days
Visual Indicators	Red, amber and green status LED
Front Button Function	Test or silence interconnected device
Rear Switch Function	RF LEARN mode
Wireless Range	> 100m in free space
Operating Temperature Range	0°C to 40°C
Storage Temperature Range	20°C to +60°C
Humidity Range	0% to 90% RH, non-condensing
Alarm Dimensions	79 x 79 x 23mm
Alarm Weight (including batteries)	62g
Mounting Options	Wall-mounted (with tamperproof latch) and freestanding
Number of Interconnected Units	32
Case Quantity	1 unit
Compliance	CE, UKCA
Warranty	10-year manufacturer’s warranty
